SGT-MOSFET采用國際先進的工藝技術，目前已開發出25V~100V的SGT-MOS平台，正在開發150V SGT-MOS平台。
采用獨特的版圖和(hé / huò)結構設計，提高芯片功率密度以及可靠性，基于卓越的研發及設計能力，低電壓SGT産品已成功實現目前國内同級産品中最優水平的綜合性能。
SGT-MOS的主要(yào / yāo)應用爲(wéi / wèi)開關電源、DC-DC轉換器、馬達控制等。
| Product | Package | Configuration | Polarity | VDS | ID | VGS | VGS(th) | RDS(on)@ 4.5V | RDS(on)@10V | Qg | |||
| Min. | Max. | Typ. | Max. | Typ. | Max. | Typ. | |||||||
| V | A | V | V | V | mΩ | mΩ | mΩ | mΩ | nC | ||||
| JMV3708NA | DFN 3.3x3.3 | Single | N | 25 | 80 | ±10 | 0.4 | 1.2 | 1.7 | 2.2 | - | - | 28.1 |
| JMV3809N | DFN 3.3x3.3 | Single | N | 25 | 22 | ±10 | 0.4 | 1.2 | 9 | 11.7 | - | - | 5.5 |
| JMT3801N | DFN 3.3x3.3 | Dual | N | 25 | 24 | ±10 | 0.4 | 1.2 | 9.8 | 12 | - | - | 8.9 |
| JMM4719ND | DFN 5x6 | Single | N | 30 | 173 | ±20 | 1.1 | 2.2 | 1.2 | 1.55 | 0.85 | 1.05 | 107 |
| JMM4719N | DFN 5x6 | Single | N | 30 | 173 | ±20 | 1.1 | 2.2 | 1.2 | 1.55 | 0.85 | 1.05 | 107 |
| JMV4720ND | DFN 3.3x3.3 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 2.9 | 3.7 | 1.9 | 2.4 | 32 |
| JMM4720N | DFN 5x6 | Single | N | 30 | 70 | ±20 | 1.1 | 2.2 | 3.1 | 4 | 2.1 | 2.7 | 32 |
| JMV4708ND | DFN 3.3x3.3 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 2.9 | 3.7 | 1.9 | 2.4 | 29.5 |
| JMV4708ND | DFN 3.3x3.3 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 2.9 | 3.7 | 1.9 | 2.4 | 29.5 |
| JMM4708ND | DFN 5x6 | Single | N | 30 | 75 | ±20 | 1.1 | 2.2 | 3 | 3.8 | 2 | 2.5 | 29.5 |
| JMM4708N | DFN 5x6 | Single | N | 30 | 73 | ±20 | 1.1 | 2.2 | 3.1 | 4 | 2.1 | 2.7 | 29.5 |
| JMM4808N | DFN 5x6 | Single | N | 30 | 70 | ±20 | 1.1 | 2.2 | 3.3 | 4.2 | 2.3 | 2.9 | 29.5 |
| JMV4808N | DFN 3.3x3.3 | Single | N | 30 | 66 | ±20 | 1.1 | 2.2 | 3.6 | 4.6 | 2.6 | 3.3 | 29.5 |
| JMD4808N | TO-252 | Single | N | 30 | 74 | ±20 | 1.1 | 2.2 | 3.7 | 4.7 | 2.7 | 3.4 | 29.5 |
| JMP4708N | TO-220 | Single | N | 30 | 70 | ±20 | 1.1 | 2.2 | 3.9 | 5 | 2.9 | 3.7 | 29.5 |
| JMV4812N | DFN 3.3x3.3 | Single | N | 30 | 43 | ±20 | 1.1 | 2.2 | 6.5 | 8 | 4.1 | 5 | 17.4 |
| JMM4812N | DFN 5x6 | Single | N | 30 | 43 | ±20 | 1.1 | 2.2 | 6.5 | 8 | 4.1 | 5 | 17.4 |
| JMD4812N | TO-252 | Single | N | 30 | 36 | ±20 | 1.1 | 2.2 | 7.1 | 8.9 | 4.7 | 6.1 | 17.4 |
| JMM4716N | DFN 5x6 | Single | N | 30 | 21 | ±20 | 1.1 | 2.2 | 10.6 | 13.8 | 6.6 | 8.6 | 10.9 |
| JMS4710N | DFN 3x3 | Dual | N | 30 | 18 | ±20 | 1.1 | 2.2 | 13.3 | 17.2 | 8.3 | 10.7 | 8.8 |
| JMS4710N | DFN 3x3 | Dual | N | 30 | 18 | ±20 | 1.1 | 2.2 | 10.9 | 14.1 | 6.9 | 8.9 | 10.9 |
| JMM5770N | DFN 5x6 | Single | N | 40 | 132 | ±20 | 1.1 | 2.2 | 1.4 | 1.8 | 1.1 | 1.4 | 97 |
| JMM5770ND | DFN 5x6 | Single | N | 40 | 138 | ±20 | 1.1 | 2.2 | 1.4 | 1.8 | 1.1 | 1.4 | 97 |
| JMP5770N | TO-220 | Single | N | 40 | 113 | ±20 | 1.1 | 2.2 | 2 | 2.6 | 1.6 | 2.1 | 97 |
| JMM5771N | DFN 5x6 | Single | N | 40 | 81 | ±20 | 1.1 | 2.2 | 2.8 | 3.6 | 2.1 | 2.6 | 46 |
| JMV5772ND | DFN 3.3x3.3 | Single | N | 40 | 63 | ±20 | 1.1 | 2.2 | 3.8 | 4.9 | 2.8 | 3.4 | 39 |
| JMM5772N | DFN 5x6 | Single | N | 40 | 61 | ±20 | 1.1 | 2.2 | 4 | 5.2 | 3 | 3.6 | 39 |
| JMV5751N | DFN 3.3x3.3 | Single | N | 40 | 39 | ±20 | 1.1 | 2.2 | 7.5 | 9.8 | 5 | 6 | 15.3 |
| JMM6715N | DFN 5x6 | Single | N | 60 | 79 | ±20 | 1.2 | 2.2 | 3.4 | 4.4 | 2.4 | 2.9 | 54 |
| JMM6715ND | DFN 5x6 | Single | N | 60 | 77 | ±20 | 1.2 | 2.2 | 3.6 | 4.7 | 2.6 | 3.1 | 54 |
| JMM6716N | DFN 5x6 | Single | N | 60 | 96 | ±20 | 1.2 | 2.2 | 2.2 | 2.8 | 1.8 | 2.4 | 89 |
| JMM6716ND | DFN 5x6 | Single | N | 60 | 104 | ±20 | 1.2 | 2.2 | 2.2 | 2.8 | 1.8 | 2.4 | 89 |
| JMP6716N | TO-220 | Single | N | 60 | 94 | ±20 | 1.2 | 2.2 | 2.6 | 3.4 | 2.1 | 2.7 | 89 |
| JMM8701N | DFN 5x6 | Single | N | 100 | 94 | ±20 | 1.5 | 2.5 | 5.3 | 6.9 | 4.2 | 5 | - |
| JMP8701N | TO-220 | Single | N | 100 | 89 | ±20 | 1.5 | 2.5 | 5.8 | 7.5 | 4.7 | 5.6 | - |
| JMG8701N | TO-263 | Single | N | 100 | 89 | ±20 | 1.5 | 2.5 | 5.8 | 7.5 | 4.7 | 5.6 | - |
